Description
MAG1116 is a powerful intelligent PA system center. It is a 10 zones PA system solution. It has all the functions
needed for a normal PA project, such as background music playing, programed audio playing, remote paging,
fire alarm, etc.
It supports 5 audio inputs and 10 zones outputs. The audio sources support AUX inputs, USB,SD, Tuner, etc. It
supports AB line speaker outputs (background music & emergency broadcast).
The system supports remote paging and programed timer function, which makes it easier for the management
of the daily running
The use of industrial PCB along with DSPPA professional design makes the system reliable and stable. It is a
cost-effective and reliable PA solution for small to medium venues like school, supermarket, factory, etc.
| No. | Item | Indicator requirement | Unit | |
| 1 | Channel B output
At 1V/1KHZ sine wave |
Microphone input sensitivity | 2–3.5 | mV |
| Wireless microphone input sensitivity | 200–350 | mV | ||
| Remote paging input sensitivity (voltage at pin No.8 and No.9) | 1000±100 | mV | ||
| Line recording input sensitivity | 200–350 | mV | ||
| Microphone recording input sensitivity | 2–3.5 | mV | ||
| 2 | Channel A output
At 1V/1KHZ sine wave |
MP3 input sensitivity | 200–350 | mV |
| Line recording input sensitivity | 200–350 | mV | ||
| Microphone recording input sensitivity | 2–3.5 | mV | ||
| 3 | Maximum noise | Channel A/B (When channel B is switched to wireless microphone) | ≤0.5 | mV |
| When channel B is switched to local microphone input | ≤1 | mV | ||
| Monitoring | ≤1.5 | mV | ||
| 4 | Degree of distortion
(Output of 1KHZ 1V) |
Channel A/B (Input of line) | ≤0.3 | % |
| Channel B (Input of local microphone) | ≤0.5 | % | ||
| 5 | Frequency response (±3dB) | Microphone input frequency response | 50—20K | HZ |
| Remote paging microphone input frequency response | 50—20K | HZ | ||
| Wireless microphone input frequency response | 100—20K | HZ | ||
| MP3 output frequency response | 200—20K | HZ | ||
| Line recording input frequency response (output of channel A) | 350—20K | HZ | ||
| Line recording input frequency response (output of channel B) | 100—10K | HZ | ||
| 6 | Monitoring | (220V power supply/1KHZ, ≤1% degree of distortion) | 6-7.5 | V |
| (+24V power supply/1KHZ, ≤1% degree of distortion) | 5-6 | V | ||
| 7 | Protection | 1.AC220V/ 1A; 2.DC+24V/2A (Only for MAG1116D) | ||
| 8 | Dielectric strength test | Between poles of power supply and input/output terminal | 4200 | VDC |
| Between poles of power supply and metal shell | 2200 | VDC | ||
| 9 | Net weight | 8kg | ||
| 10 | Gross weight | 9.5kg | ||
| 11 | Machine Dimension (L×W×H) | 483×350×88mm | ||
| 12 | Package Dimension (L×W×H) | 555×455×185mm | ||
