Description
Key Specifications
| Dimension (H x W x D) (mm) | 133 x 430 x 365 mm |
| Operating temperature (°C) | -10 – 45 °C |
| Power consumption (W) | 720 W |
| Weight (kg) | 18 kg |
| Quantity | Component |
|---|---|
| 1 | All‑in‑One Unit |
| 1 m | Cat‑5 cable with RJ45 termination for adaptor |
| 1 | Adaptor to connect a PLE‑1CS or PLE‑1SCS desktop microphone via shielded Cat‑5 wiring |
| 1 | AC power cord (for European mains sockets) |
| 1 | Safety Instructions |
| 1 | AM indoor antenna |
| 1 | Coax connector for FM antenna |
| 1 | Pair of brackets for 19“ rack installation |
| 1 | Remote control unit (without batteries) |
| 1 | Installation and Operating Manual |
The Plena All‑in‑One System is a six‑zone 240 W background music and paging system, which consists of the Plena All‑in‑One Unit, an optional remote Wall Panel, and one or more Call Stations. It is a costeffective public address system for small to mediumsized venues that require an easy‑to‑use out‑of‑the‑box solution.
The Plena All‑in‑One Unit can provide hours of uninterrupted music from USB or SD flash memory. The unit also has a built in AM/FM tuner with presets. To ensure for optimum performance, the All‑in‑One Unit has no moving parts, such as hard drives that can fail or wear out. It is compatible with SD, SDHC and MMC cards, and USB memory sticks. The unit is supplied with an IR remote control for controlling the music source. To enhance the performance of the public address system, the following optional products can be connected to the
All‑in‑One Unit: One or more Call Stations for six‑zones and all‑call, so that calls can be made to any combination of zones or all zones. A maximum of six Call Stations can be connected in a loop‑through arrangement to the same All‑in‑One Unit.
• A Wall Panel for enabling control of the background music from a remote location; the Wall Panel even allows a microphone or portable music player to be connected to the system.
• An additional power amplifier, so that music can be heard in one set of zones while calls can be made to another set of zones. The All‑in‑One Unit is a 3 U high 19” wide rack‑mount unit. The unit is supplied with detachable rack‑mount brackets so that it can be used on a tabletop or installed in a rack.
